Essex KTP-103 Stainless Piezo Passthrough Extreme codepad

Out of Stock

SKU: E36023

Essex KTP-103 Stainless Piezo Passthrough Extreme codepad

The KTP-103-SN is a 26-bit Wiegand, 12-button (3×4) Keypad reader with a stainless steel overlay and waterproof design capable of withstanding even the most extreme environments.

This heavy duty piezoelectric keypad ensures reliable performance for over one billion cycles. The KTP-103-SN has no moving parts, meaning almost no maintenance is required, and the unit comes backed by a limited lifetime warranty.

The KTP-103-SN mounts easily to a surface or Single Gang Switchbox.

Life Cycle > 1 Billion Cycles Keypad Switch
Operating Environment 100% Relative Humidity / – 40 F to + 160F (-40C to + 70C)
Dimensions H: 5 x W: 3 x D: 7/16 (13 x 8.6 x 1.1 cm)
Input Voltage 5 or 12V Field Selectable (Except X-Y and 2 of 7 outputs)
Standby Current Draw <20mA
Mounting Single Gang Switchbox, Surface Mount
