Bosch External Metal 6x2 Combo Keypad and Smartcard Reader (E43332) *** Supersedes CP151B ***

SKU:CP156B

Please login or register to view pricing.


Bosch External Metal 6x2 Combo Keypad and Smartcard Reader (CP156B) *** REPLACEMENT TO CP151B *** The CP156B keypad provides alarm and or access control functionality when used on selected Solution security control panels. It is fitted with built in smart prox reader, front and rear tamper. Constructed from high strength zinc alloy die cast housing, the CP156B keypad provides a high level of durability and is also weather resistant to IP65 making it ideal for external installations. The CP156B includes red, green and blue indicators which are used to show area or door lock status. Backlit buttons make it easy to operate in all lighting conditions. CP156B Specifications Part Number: CP156B - External 6x2 Metal Keypad With Smart Card Reader (IP67). Operating Voltage: 10.0V D.C. - 14.5V D.C. @ 100mA Max. Module Connection: (RS485 LAN) Max total LAN length using multi strand security cable = 500m. Max total LAN length using 2 pair twisted shielded data cable (Belden 8723) = 1200m. See the control panel manual for complete wiring instructions. Lock Output: Relay 2Amp DC Egress Input: Low to trigger. Can be disabled via software control. Dimensions: 45mm(W), 23mm(D), 162mm(H). CM444B = 46mm(W), 12.5mm(D), 12mm H) Environment: -30˚ to 55˚C RH 5 to 85% at 30˚C non-condensing. Fixing Method: The CP156B should be mounted on a sturdy vertical wall using fixtures appropriate for the wall construction type. Warranty: 3 years from date of manufacture (return to base).

(CP156B)

SKU CP156B
Brand Bosch
Unit Of Measure Each
Assembled Length 0.175m
Assembled Height 0.065m
Assembled Width 0.165m
Type Stock
